- Logging, audit trail function and export function (USB encryption export or host computer serial port export)
- Have an electronic signature function that meets FDA requirements to ensure that test data is more objective
- Data real-time recording and export function (USB encryption export or host computer serial port export)
- Fault monitoring, alarm, recording and export functions (USB encryption export or host computer serial port export)
-4 level password function: login password, operator password, administrator password, advanced administrator password
- Three power-off mode selection functions: power-off reply, stop or restart
- Historical data and historical curve query and download functions
- Maximum support for expanding 32GTF memory cards, which can store at least 10 years of data;
- Ambient temperature detection function
-PDF data export function (exported by PC software)
- Computer monitoring software monitoring and synchronization control functions, supporting 20 devices for simultaneous control.
- Network function for remote monitoring.
- Water level monitoring and automatic water replenishment
-Microneedle printer
-3Q service
Professional air supply design:
The air duct of the volute of the built-in deflector fan ensures that the air temperature field in the box is uniform and the temperature deviation is small;
Cooling down:
Fin-type high-efficiency evaporator, strong anti-frosting ability, small heat transfer temperature difference, fast cooling rate;
Low power consumption:
Compressor return air cooling circuit and energy regulation circuit; optional "cold end output" type, more effective energy saving.
Refrigeration:
The use of France Taikang fully enclosed compressor, safety protection features, high reliability; the main refrigeration accessories are using world-class brand products; efficient US ALCO oil separator, oil separation efficiency of up to 99%, to ensure compressor life.
Compressor suction pressure regulation and protection to ensure various conditions
Cabinet:
The thermal insulation box is made of 304 stainless steel inner wall and the outer wall is made of color steel plate.
Insulation:
High temperature resistant PU (polyurethane) foam + ultra-fine centrifugal glass wool composite insulation layer with a thickness of 60mm;
Humidifier automatic water supply system.
The RO water purifier is installed behind the cabinet or at the user's tap water source. The tank is equipped with a high water storage tank and an automatic water level control device.
RO water purifier can carry out three-stage filtration + reverse osmosis treatment + post-filtration of tap water to ensure the water quality supplied to the humidifier reaches the water quality requirements of pure water or deionized water, reduce the labor intensity of the tester's operation and maintenance, and avoid The test was interrupted due to lack of water.
| Content product | Customizable |
| Temperature range | 20℃~+65℃（customizable） |
| Temperature fluctuation | ≤±0.5℃ |
| Temperature deviation | ≤±1.0℃ |
| Temperature uniformity | ≤1.0℃ |
| Heating rate | 1℃/min；（Optional） |
| Humidity range | 30~95%RH（+20℃~+65℃）Customizable |
| Humidity deviation | ±2%R.H（Humidity deviation when ≤75%R.H：±2%R.H） |
| Inner box | Stainless steel plate SUS304 |
| Outer box | Color steel plate |
| Observation window | Multi-layer hollow electric heating glass |
| Refrigeration Compressors | Imported compressor |
| Refrigerants | Environmentally friendly refrigerant |
| cooling method | Air cooled |
| Monitor | 7 inches640X480，Color touch screen |
| Display resolution | Temperature 0.1 ° C; humidity: 0.1% RH; time 0.1 minutes |
| Sensor | Class A Pt100 armored platinum resistor |
| Memory | 4G U disk |
| Voltage | AC220V single phase + protective ground wire |
| Wind speed | 1.0~1.7m/s |
| Noise | ≤65dB（A），Measured one meter above the ground directly in front of the box |
-The test technical data is only applicable to the test results under the no-load condition of the equipment and the ambient temperature is 25 degrees!
-The appearance and parameters of the product are subject to change without notice. The appearance of the product may vary due to photography and printing. Please understand!
Computer monitoring software
Paperless recorder
SMS alarm
